Case IH 71-89 Mag-STX/MF/NH T8000-TG LED Cab/Handrail Light – Swivel Side Mount
This light has a swivel mounting bracket, which allows for better angles to mount the light. Uses Original Mount & Wiring. Includes: Stainless Steel Hardware, Mounting Bracket, Plug & Play.
Replaces OEM Part Numbers:
Case/IH: 92266C1, 275333A1, 275334A1
Massey Ferguson: 3900811M91, 3781544M1, 3900812M91
Features:
- IP67 Waterproof
- EMC CISPR 25 Class 4
- E-mark, ECE R10, RoHS
- Side swivel mounting bracket
Spefications
Applications
Spefications
| Description | LED Side Mount Light with Swivel Bracket | Wattage | 40 |
| Dimensions(WxHxD) | 6″ x 3.5″ x 3″ | Voltage | 10-30V DC |
| Lumens | 3600 | Light Pattern | Flood |
| Amps | 3.33 | Warranty | 2 Years |
- Uses original mount and wiring
- Swivel mounting bracket, which allows for better angles to mount the light
- Includes stainless steel hardware and mounting bracket
Applications
Case IH® 5100-5200 Series Maxxum, 71-89 Series Magnum, Magnum, MX Series Maxxum, MX, Steiger and STX Steiger 4WD Series Tractors:
- 5100 Series Maxxum: 5120, 5130, 5140
- 5200 Series Maxxum: 5220, 5230, 5240, 5250
- 71 Series Magnum: 7110, 7120, 7130, 7140, 7150
- 72 Series Magnum: 7210, 7220, 7230, 7240, 7250
- 89 Series Magnum: 8910, 8920, 8930, 8940, 8950
- Magnum Series: Magnum 180, Magnum 190, Magnum 210, Magnum 215, Magnum 225, Magnum 235, Magnum 245, Magnum 250, Magnum 255, Magnum 260, Magnum 275, Magnum 280, Magnum 290, Magnum 305, Magnum 310, Magnum 315, Magnum 335, Magnum 340, Magnum 370, Magnum 380
- MX Series Maxxum: MX100, MX120, MX135, MX150, MX170, MX215, MX245, MX275, MX305
- MX Series: MX80C, MX90C, MX100C
- Steiger Series: Steiger 280, Steiger 285, Steiger 330, Steiger 335, Steiger 380, Steiger 385, Steiger 430, Steiger 435, Steiger 480, Steiger 485, Steiger 530, Steiger 535
- STX Series Steiger 4WD: STX275, STX280, STX325, STX330, STX375, STX380, STX425, STX430, STX440, STX450, STX480, STX485, STX500, STX530
Replaces Case IH® Part Number: 92266C1, 275333A1, 275334A1
Massey Ferguson® Tractors: 6235, 6245, 6255, 6265, 6270, 6280, 6290
Replaces Massey Ferguson® Part Numbers: 3900811M91, 3781544M1, 3900812M91
New Holland® T8000 and TG Series Tractors:
- T8000 Series: T8010, T8020, T8030, T8040, T8050
- TG Series: TG215, TG245, TG275, TG305
